Drawer Slide- Full Extension- 20″- 100 Lb Capacity- Pair

Sale!
Drawer Slide- Full Extension- 20"- 100 Lb Capacity- Pair

Drawer Slide- Full Extension- 20″- 100 Lb Capacity- Pair

Original price was: $19.67.Current price is: $11.87.

20 in stock

SKU: SG25282 Category:

Description

start of prefixes

end of prefixes

start of suffixes

Knape & Vogt Model 8400P20 Precision Full Extension Drawer SlidePRODUCT OVERVIEWMedium-duty, precision slides for box drawer or pedestal file drawers up to 24″ wide. For frame and frameless construction. May be used horizontal position with a reduced load rating of 30 pounds. Height:1-13/16″ Clearance required: 1/2″ plus 1/32″ minus 0 each side. Features telescoping, full extension on precision steel ball bearings. 32mm hole pattern with direct access mounting. Lever disconnect for easy drawer removal. Ball retainer latch and ramps, for easy drawer insertion. Drawer adjustment without removal. Flexible mounting tabs self-adjust to side clearance. Metal ball retainer holds 3 bearings per inch of race for smooth and quiet motion. Polymer stop cushions. Non-handed. Packaged with screws and installation instructions.

end of suffixes
