Fluidyne FM1SA201K200NBN 200CC 2-Bolt SAE A Flange Motor

Description

The Fluidyne FM1SA201K200NBN is a robust orbital motor ideal for various hydraulic applications, delivering dependable performance and efficiency. Its precision engineering ensures smooth operation, making it suitable for demanding environments such as industrial machinery and mobile systems.

Specifications

• Model Number: FM1SA201K200NBN
• Displacement: 200 CC (12.2 In³)
• Mount Type: 2-Bolt SAE A Flange Mount
• Shaft Type: 1″ Woodruff Keyed Shaft
• Ports: 1/2 NPT Ports
• Width: 1.456″ (37mm)
• Case Drain: 7/16-20 O’Ring Case Drain (Plugged)
• Finish: Black Paint

Features and Benefits

• High-performance design for enhanced efficiency
• Durable construction optimized for longevity
• Versatile installation with 2-bolt SAE A flange configuration
• Easily accessible ports for simple maintenance
• Made in USA under stringent quality control processes

Applications

• Industrial machinery
• Construction equipment
• Material handling systems
• Agricultural machinery
• Mobile hydraulic systems

Quality and Certification

The Fluidyne FM1SA201K200NBN motor is manufactured following rigorous Fluidyne quality standards and is compliant with industry certifications. Each unit undergoes extensive testing to ensure high performance and durability.

For technical support and assistance, contact our product specialists at (800) 823-4937

Danfoss, Charlynn FM1SA201K200NBN Quality Made Aftermarket Replacement with a 12-month manufacturer’s warranty
