Fluidyne FM34SQ06B100MBN Orbital Motor 100CC 4-Bolt SAE A

Description

The Fluidyne FM34SQ06B100MBN orbital motor is a high-performance hydraulic solution designed for a range of industrial applications.Built with precision engineering, this motor delivers exceptional power efficiency and operates smoothly under demanding conditions.

Specifications

• Model Number: FM34SQ06B100MBN
• Displacement: 100 CC
• Mount Type: 4 Bolt SAE A Square Flange
• Shaft Type: 1″ 6B Splined Shaft
• Ports: Manifold Ports 10MM; 4X5/16-18
• Width: 0.79″ (20MM)
• Case Drain: No Case Drain (7/16-20 O’Ring; Plugged)
• Paint Status: Black Paint

Features and Benefits

• Designed for high torque applications with a robust construction
• Flexible installation options with 4-bolt mounting
• Reliable performance in various environments
• Compact and lightweight design for easy integration
• Made in USA, ensuring quality craftsmanship and compliance with industry standards

Applications

• Industrial machines
• Material handling systems
• Agricultural machinery
• Construction equipment
• Mobile hydraulic applications

Quality and Certification

This Fluidyne motor adheres to rigorous quality standards and is backed by certifications that guarantee its reliability and efficiency in hydraulic applications. The manufacturing process includes comprehensive testing of all components to secure exceptional performance and durability.

For technical support and assistance, contact our product specialists at (800) 823-4937

Danfoss, Charlynn FM34SQ06B100MBN Quality Made Aftermarket Replacement with a 12-month manufacturer’s warranty
